CONE DRIVE NO6 (COMING SOON)

Features

• An entry level machine designed to last.

• Infinitely variable dependent on foot pedal position

• Corrosion resistant aluminium tray and wheel head. Steel frame/body zinc plated and powder coated for extreme corrosion resistance

• Compact size is perfect for small spaces.

• Foot operated speed control

Specifications

• Model: No6 MKII

• Motor: 370w (1/2hp)

• Drive system: Cone Drive

• Average speed range: Infinitely variable 0 - 240rpm

• Wheel-head direction: Counterclockwise

• Wheel-head: 2800mm (11inch) machined marine grade alloy casting

• Dimension: (Lmm x (W)mm x (H)mm

• Weight: 30kg

• Warranty period: 18 months

Optional Extras

CONE DRIVE NO3

Features

• One of the hardest wearing wheels available – used by many schools worldwide

• Infinitely variable dependent on foot pedal position

• Free wheeling wheel head

• Corrosion resistant aluminium tray and wheel head. Steel frame/body zinc plated and powder coated for extreme corrosion resistance

• Light weight and compact

• Foot operated speed control

Specifications

• Model: No3 MKII

• Motor: 370w (1/2hp)

• Drive system: Cone Drive

• Average speed range: Infinitely variable 0 - 240rpm

• Wheel-head direction: Counterclockwise

• Wheel-head: 330mm (13inch) machined marine grade alloy casting

• Dimension: (L)685mm x (W)508mm x (H)558mm

• Weight: 35.3kg

• Warranty period: 36 months

Optional Extras

• Clip-on tray shelves – hand oiled plywood with aluminium brackets

• Standard wheel head bats – drilled with holes to match wheel head. hand oiled plywood) approx 340mm diameter

• Riser bats – increased thickness bat for increasing the wheel head height above that of the tray rim for throwing large diameter platters etc. Made from hand oiled plywood.

• Comfortable padded seat

DIRECT DRIVE GO

Features

• A Table top version of our Glide wheel

• Motor: Direct drive 400W permanent magnet. No belts or pulleys (nothing to tension, no belt thump). Brushless design (maintenance free).

• Corrosion resistant aluminium tray and wheel head. Steel frame/body zinc plated and powder coated for extreme corrosion resistance

• Ergonomic foot pedal with easy adjustment.

• Intelligent microprocessor based control system for smooth, precise control

• Easy clean touch pad control on side of wheel - forward and reverse button

• Energy efficient – low power consumption

Specifications

• Model: Direct Drive Go

• Motor: 400W

• Drive system: Brushless direct drive motor

• Average speed range: Infinitely variable 0 - 260rpm

• Wheel-head direction: Clockwise/counter-clockwise, switch controlled

• Wheel-head: 330mm (13inch) machined marine grade alloy casting

• Dimension: (L)xmm x (W)xmm x (H)xmm

• Weight: 24.4kg

• Warranty period: 36 months

Optional Extras

• Clip-on tray shelves - hand oiled plywood with aluminium brackets

• Standard wheel head bats – drilled with holes to match wheel head. hand oiled plywood) approx 340mm diameter

• Riser bats – increased thickness bat for increasing the wheel head height above that of the tray rim for throwing large diameter platters etc. Made from hand oiled plywood.

DIRECT DRIVE GLIDE

Features

• An affordable step into a Direct Drive wheel.

• Motor: Direct drive 400W permanent magnet. No belts or pulleys (nothing to tension, no belt thump). Brushless design (maintenance free).

• Corrosion resistant aluminium tray and wheel head. Steel frame/body zinc plated and powder coated for extreme corrosion resistance

• Ergonomic foot pedal with easy adjustment.

• Intelligent microprocessor based control system for smooth, precise control

• Easy clean touch pad control on side of wheel - forward and reverse button

• Energy efficient – low power consumption

Specifications

• Model: Direct Drive Glide

• Motor: 400W

• Drive system: Brushless direct drive motor

• Average speed range: Infinitely variable 0 - 260rpm

• Wheel-head direction: Clockwise/counter-clockwise, switch controlled

• Wheel-head: 330mm (13inch) machined marine grade alloy casting

• Dimension: (L)685mm x (W)508mm x (H)558mm

• Weight: 27.6kg

• Warranty period: 36 months

Optional Extras

• Clip-on tray shelves - hand oiled plywood with aluminium brackets

• Standard wheel head bats – drilled with holes to match wheel head. hand oiled plywood) approx 340mm diameter

• Riser bats – increased thickness bat for increasing the wheel head height above that of the tray rim for throwing large diameter platters etc. Made from hand oiled plywood.

• Comfortable padded seat

DIRECT DRIVE FLOW

Features

• A Premium Direct Drive wheel with a wider speed range and more torque than the Direct Drive Glide.

• Motor: Direct drive 600W permanent magnet. No belts or pulleys (nothing to tension, no belt thump). Brushless design (maintenance free).

• Corrosion resistant aluminium tray and wheel head. Steel frame/body zinc plated and powder coated for extreme corrosion resistance

• Ergonomic foot pedal with easy adjustment.

• Intelligent microprocessor based control system for smooth, precise control

• Easy clean touch pad control on side of wheel - forward and reverse button

Specifications

• Model: Direct Drive Flow

• Motor: 600W

• Drive system: Brushless direct drive motor

• Average speed range: Infinitely variable 0 - 300rpm

• Wheel-head direction: Clockwise/counter-clockwise, switch controlled

• Wheel-head: 330mm (13inch) machined marine grade alloy casting

• Dimension: (L)685mm x (W)508mm x (H)558mm

• Weight: 27.6kg

• Warranty period: 36 months

Optional Extras

• Clip-on tray shelves - hand oiled plywood with aluminium brackets

• Standard wheel head bats – drilled with holes to match wheel head. hand oiled plywood) approx 340mm diameter

• Riser bats – increased thickness bat for increasing the wheel head height above that of the tray rim for throwing large diameter platters etc. Made from hand oiled plywood.

• Comfortable padded seat
